在学习VIT之前，建议先把 Transformer 搞明白了：【transformer】入门与理解

做了那些改进？

看图就比较明白了，VIT只用了Encoder的部分，把每一个图片裁剪成若干子图，然后把一个子图flatten一下，当成nlp中的一个token处理。
值得注意的是，在首个 token中嵌入了一个 class_token，维度为（1，embed_dim=768），这个class_token在预测的时候比较有意思，见下图：

注意上图中有些细节遗漏，全流程应该是：先把输入进行 patch_embedding 变成 visual tokens，然后和 class_token 合并，最后 position_embedding。

另外需要注意的是，class_token 是一个可学习的参数，并不是每次输入时都需要输入的类别数值。

self.class_token = nn.Parameter(torch.ones(1, 1, embed_dim) * 0.98)  #(1,1,768)

代码

其实有了 Transformer 的基础后，直接看代码就知道VIT是怎么做的了。

import copy
import torch
import torch.nn as nn

# 所有基于nn.Module结构的模版，可以删掉
class Identity(nn.Module):
    def __init__(self):
        super().__init__()

    def forward(self, x):
        return x


class Mlp(nn.Module):
    def __init__(self, embed_dim, mlp_ratio, dropout=0.):
        super().__init__()
        self.fc1 = nn.Linear(embed_dim, int(embed_dim * mlp_ratio)) # 中间层扩增
        self.fc2 = nn.Linear(int(embed_dim * mlp_ratio), embed_dim)
        self.act = nn.GELU()
        self.dropout = nn.Dropout(dropout)

    def forward(self, x):
        # TODO
        x = self.fc1(x)
        x = self.act(x)
        x = self.dropout(x)
        x = self.fc2(x)
        x = self.dropout(x)
        return x


class PatchEmbedding(nn.Module):
    def __init__(self, image_size=224, patch_size=16, in_channels=3, embed_dim=768, dropout=0.):
        super().__init__()
        n_patches = (image_size // patch_size) * (image_size // patch_size)  # 196 个 patch
        self.patch_embedding = nn.Conv2d(in_channels=in_channels,  # embedding 操作后变成 torch.Size([10, 768, 14, 14])
                                         out_channels=embed_dim,
                                         kernel_size=patch_size,
                                         stride=patch_size)
        self.dropout = nn.Dropout(dropout)

        # TODO: add class token
        self.class_token = nn.Parameter(torch.ones(1, 1, embed_dim) * 0.98)  #(1,1,768)

        # TODO: add position embedding
        self.position_embedding = nn.Parameter(torch.ones(1, n_patches+1, embed_dim) * 0.98)  #(1,196+1,768)

    def forward(self, x): # 先把 x patch_embedding，然后和 class_token 合并，最后 position_embedding
        # [n, c, h, w]
        cls_tokens = self.class_token.expand([x.shape[0], -1, -1]) #(10,1,768) 根据batch扩增 class_token
        x = self.patch_embedding(x) # [n, embed_dim, h', w']
        x = x.flatten(2) # torch.Size([10, 768, 196])
        x = x.permute([0, 2, 1]) # torch.Size([10, 196, 768])
        x = torch.concat([cls_tokens, x], axis=1) # (10,196+1,768)
        x = x + self.position_embedding
        return x # torch.Size([10, 197, 768])


class Attention(nn.Module):
    """multi-head self attention"""
    def __init__(self, embed_dim, num_heads, qkv_bias=True, dropout=0., attention_dropout=0.):
        super().__init__()
        self.num_heads = num_heads
        self.head_dim = int(embed_dim / num_heads) # 768/4=192
        self.all_head_dim = self.head_dim * num_heads
        self.scales = self.head_dim ** -0.5

        self.qkv = nn.Linear(embed_dim,
                             self.all_head_dim * 3) # [768, 768*3]

        self.proj = nn.Linear(embed_dim, embed_dim)

        self.dropout = nn.Dropout(dropout)
        self.attention_dropout = nn.Dropout(attention_dropout)
        self.softmax = nn.Softmax()

    def transpose_multihead(self, x):
        # x: [N, num_patches 197, all_head_dim 768] -> [N, n_heads, num_patches, head_dim]
        new_shape = [x.shape[:-1][0], x.shape[:-1][1], self.num_heads, self.head_dim] # [10, 197, 4, 192]
        x = x.reshape(new_shape)
        x = x.permute([0, 2, 1, 3]) # [10, 4, 197, 192]
        return x

    def forward(self, x): # Attention 前后输入输出维度不变，都是 [10, 197, 768]
        B, N, _ = x.shape   # torch.Size([10, 197, 768])
        qkv = self.qkv(x).chunk(3, axis=-1) # 含有三个元素的列表，每一个元素大小 [10, 197, 768]
        q, k, v = map(self.transpose_multihead, qkv) # [10, 4, 197, 192]
        attn = torch.matmul(q, k.transpose(2,3)) # [10, 4, 197, 197]
        attn = attn * self.scales
        attn = self.softmax(attn)
        attn = self.attention_dropout(attn)

        out = torch.matmul(attn, v) # [10, 4, 197, 192]
        out = out.permute([0, 2, 1, 3]) # [10, 197, 4, 192]
        out = out.reshape([B, N, -1]) # [10, 197, 768]

        out = self.proj(out) # [10, 197, 768]
        out = self.dropout(out)

        return out

class EncoderModule(nn.Module):
    def __init__(self, embed_dim=768, num_heads=4, qkv_bias=True, mlp_ratio=4.0, dropout=0., attention_dropout=0.):
        super().__init__()
        self.attn_norm = nn.LayerNorm(embed_dim)
        self.attn = Attention(embed_dim, num_heads)
        self.mlp_norm = nn.LayerNorm(embed_dim)
        self.mlp = Mlp(embed_dim, mlp_ratio)

    def forward(self, x):
        h = x # residual
        x = self.attn_norm(x)
        x = self.attn(x)
        x = x + h

        h = x # residual
        x = self.mlp_norm(x)
        x = self.mlp(x)
        x = x + h
        return x

class Encoder(nn.Module):
    def __init__(self, embed_dim, depth):
        super().__init__()
        Module_list = []
        for i in range(depth):
            encoder_Module = EncoderModule()
            Module_list.append(encoder_Module)
        self.Modules = nn.ModuleList(Module_list)
        self.norm = nn.LayerNorm(embed_dim)

    def forward(self, x):
        for Module in self.Modules:
            x = Module(x)
        x = self.norm(x)
        return x


class VisualTransformer(nn.Module):
    def __init__(self,
                 image_size=224,
                 patch_size=16,
                 in_channels=3,
                 num_classes=1000,
                 embed_dim=768,
                 depth=3,
                 num_heads=8,
                 ):
        super().__init__()
        self.patch_embedding = PatchEmbedding(image_size, patch_size, in_channels, embed_dim)
        self.encoder = Encoder(embed_dim, depth)
        self.classifier = nn.Linear(embed_dim, num_classes)

    def forward(self, x):
        # x:[N, C, H, W]
        x = self.patch_embedding(x) # torch.Size([10, 197, 768])
        x = self.encoder(x) # torch.Size([10, 197, 768])
        x = self.classifier(x[:, 0]) # 注意这里的处理很奇妙哦，参考 x = torch.concat([cls_tokens, x], axis=1) # (10,196+1,768)
        return x


vit = VisualTransformer()
print(vit)

input_data = torch.randn([10,3,224,224]) # 每批次输入10张图片
print(vit(input_data).shape) # torch.Size([10, 1000])
